Biopsy pipettes are used to perform biopsies on the embryo (blastocyst) or the oocyte (polar body) for Preimplantation Genetic Diagnosis - PGD.
Standard Microtech Biopsy micropipettes are prepared from borosilicate glass tubing (O.D. 1 mm, I.D. 0,78 mm), total length 5,5 mm, the length of the arm 1mm, blunt opening (A) or beveled 40° (B) and with I.D. 10, 15, 20, 30 a 35 µm.
Biopsy micropipettes may be ordered strait or with bending angle 20°, 30°, 35° and 45°.
Biopsy micropipettes with I.D. 15 micron, beveled 40° with a spike are use for Polar body biopsy.
| Yellow | Article No. | code | I.D. | angle | Blunt opening |
|---|---|---|---|---|---|
 |
004-10-30-A | 004 | 10 | 30 | A |
| 004-10-35-A | 004 | 10 | 35 | A | |
| 004-10-A | 004 | 10 | straight | A | |
| 004-15-30-A | 004 | 15 | 30 | A | |
| 004-15-35-A | 004 | 15 | 35 | A | |
| 004-15-A | 004 | 15 | straight | A | |
| 004-30-30-A | 004 | 30 | 30 | A | |
| 004-30-35-A | 004 | 30 | 35 | A | |
| 004-30-A | 004 | 30 | straight | A | |
| 004-35-30-A | 004 | 35 | 30 | A | |
| 004-35-35-A | 004 | 35 | 35 | A | |
| 004-35-A | 004 | 35 | straight | A | |
| Yellow | Article No. | code | I.D. | angle | Beveled |
 |
004-10-30-B | 004 | 10 | 30 | B |
| 004-10-35-B | 004 | 10 | 35 | B | |
| 004-10-B | 004 | 10 | straight | B | |
| 004-15-30-B | 004 | 15 | 30 | B | |
| 004-15-35-B | 004 | 15 | 35 | B | |
| 004-15-B | 004 | 15 | straight | B | |
| 004-30-30-B | 004 | 30 | 30 | B | |
| 004-30-35-B | 004 | 30 | 35 | B | |
| 004-30-B | 004 | 30 | straight | B | |
| 004-35-30-B | 004 | 35 | 30 | B | |
| 004-35-35-B | 004 | 35 | 35 | B | |
| 004-35-B | 004 | 35 | straight | B |
